Product introduction:
Suitable material:
Puffed food (potato chips, rice crust), many kinds of nuts (peanuts, pistachio, hazelnuts), snack food (beef jerky, cuttlefish pieces, jell, melon seeds, plums), freezing food (glue pudding, dumplings), candy, seeds, pet food, irregular materials in granule, globe or piece shape.
Puffed food (potato chips, rice crust), many kinds of nuts (peanuts, pistachio, hazelnuts), snack food (beef jerky, cuttlefish pieces, jell, melon seeds, plums), freezing food (glue pudding, dumplings), candy, seeds, pet food, irregular materials in granule, globe or piece shape.
Product features:
1. High capacity pillow sealing style.
2. PLC control. Bag length, packing volume and speed can be adjusted on the screen. The user operates it directly.
3. Adopt high accurate high speed mathematical multihead electronic weigher to make metering and filling more accurate faster.
4. It can automatically finish making-bag, metering, filling, sealing, cutting, counting and printing batch number.
5. Packing material: PET/PE, PET/aluminizing/PE, PET/Al foil/PE, paper/PE, nylon and another heat-sealing compound material.
6. packing material required: 0.04mm«film thickness«0.08mm, inner diameter of film roll need 75mm at least, outer diameter of film roll need 320mm.
2. PLC control. Bag length, packing volume and speed can be adjusted on the screen. The user operates it directly.
3. Adopt high accurate high speed mathematical multihead electronic weigher to make metering and filling more accurate faster.
4. It can automatically finish making-bag, metering, filling, sealing, cutting, counting and printing batch number.
5. Packing material: PET/PE, PET/aluminizing/PE, PET/Al foil/PE, paper/PE, nylon and another heat-sealing compound material.
6. packing material required: 0.04mm«film thickness«0.08mm, inner diameter of film roll need 75mm at least, outer diameter of film roll need 320mm.
Technical parameters:
Model |
SJ-500BKW |
Bag-making length |
60-550mm |
Bag-making width |
130-290mm |
Packing film width |
280-610mm |
Packing capacity |
100-5000ml |
Packing speed |
20-50bags/min |
Power |
4.4KW |
Air power |
0.8Mpa |
Air consumption |
300ml/min |
Dimension |
1820*1180*2600mm |
Weight |
1200kg |
Sample display:
